Visit Vince Hagan at World of Concrete
January 20-22, 2026 • Las Vegas Convention Center
We’re excited to be bringing the all new HT High-Performance Series to the World of Concrete this year. This plant features all of the latest and exciting innovations from Vince Hagan. Come see if for yourself and learn about these all new features.
Our booth will also feature guided sessions about mobile batch plant maintenance best practices, sessions of the SmartVH Plant Monitoring App, and more.
Looking forward to seeing you at the show!
HT Best Practices In-Booth Training Sessions
Are you getting the most production out of your mobile batch plant? Does your team have a regular maintenance routine or need to start one? Come learn mobile batch plant maintenance tips from the company that invented it! With over 40 years of experience, Mat Rozell has done it all in concrete production. As Technical Sales Manager at Vince Hagan, he has the skills and knowledge to give you best practices for maintaining your equipment and proven strategies to optimize your production.
This exclusive training is limited to 15 participants at a time and available at 10am every day during World of Concrete. Tickets are limited and must be shown to participate in this session. Click the button below to claim your ticket now.
SmartVH Plant Monitoring App Demo
Vince Hagan developed the SmartVH Plant Monitoring app for producers across the industry. This in-depth review of the SmartVH app will cover the features and benefits of the SmartVH system on new batch plant. It will also cover how producers can add their existing equipment and take advantage of the maintenance task reminders and calendars to make sure their valuable equipment is maintained.
IN-BOOTH DEMO • DAILY • 3PM
High-Performance Series
180-200 YD³ Per Hour
As the top of the line in the series, the HT High-Performance Series combines speed, storage, versatility, and technology into a machine capable of meeting the demands of any ready mix job. For producers looking to maximize production with total mobility and layout flexibility, the HT High-Performance is for you.
This series standard features include up to 80 ton – 4 compartment aggregate bin, up to 1200 BBL cementitious storage (with dual, optional HCA silos), 12” screw feeders, powerful air compressor, and 36” conveyor belt. For greater production speed, this series includes the new Turbo-Flo Armor™ liners in the aggregate batcher and 2’ risers for optimal truck loading speed. With the combination of these components, the HT High-Performance Series is capable of meeting any output demands for high-quality concrete.
Key Specs
Performance Series
120-200 YD³ Per Hour
Stepping up to the HT Performance Series, producers recognize this mobile plant as the industry standard in ready mix concrete production. With an up to 80-ton aggregate bin, optional weighed water system, powerful air compressor, and 36” conveyor belt, the HT Performance Series is perfect for a wide range of producers needing to meet the demands of the market.
For producers in a hurry, the HT Performance Series has an optional retractable self erect system available. The cylinders retract into themselves, protecting them from the caustic environment. The self erect system eliminates the need for costly and time-consuming cranes. Customers have had their plant erected and operational in 8 hours.
Key Specs
Essential Series
120-150 YD³ Per Hour
The HT Essential Series mobile batch plant is designed to maximize production and minimize initial costs. Whether just starting out in concrete production or looking to grow market share, the HT Essential Series is stacked with features any producer needs to deliver high-quality concrete.
It comes equipped with an in-truss, PLC-based dust control system, a 65-ton aggregate bin, 400 BBL in-truss cementitious storage, and much more. With no foundations needed and universal configuration of additional storage silos and aggregate conveyors, the versatility and value of the HT Essential Series is unmatched in the industry.
Key Specs
Multi-Compartment Agg Bin
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Agg Bin | 65 Ton / 4 compartment | 65-80 Ton / 4 compartment | 80 Ton / 4 compartment |
| Moisture Probes | All Bins – Both Sides | All Bins – Both Sides | All Bins – Both Sides |
| Walls | Bolted | Bolted | Bolted |
12YD³ Agg Batcher
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Cylinders | 4″ | 4″ | 4″ |
| Liners | None | None | 1/2″ Turbo-Flo™ Armor |
| Vibrator | Electric | Electric | Electric |
400 BBL In-Truss Silo
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| 5” Fill Pipes | With 5″ Camlock (1 LH & 1 RH) | With 5″ Camlock (1 LH & 1 RH) | With 5″ Camlock (2 LH & 2 RH) |
| High Level w/Horn | Yes | Yes | Yes |
| Screwfeeder | 10″ | 10″ | 12″ |
Belt Conveyor
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Belt Width | 30” | 36” | 36” |
| Grease System | No | No | Yes |
| Heavy Duty Belt Wiper | Yes | Yes | Yes |
| Motor Size | 20 HP | 30 HP | 30 HP |
| Riser | 1′-0″ | 1′-0″ | 1′-6″ |
| Tandem Landing Gear | Yes | Yes | Yes |
| Walkway | Yes | Yes | Yes |
12YD³ / 122FT³ Cement Batcher
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Left & Right Inlet | Yes | Yes | Yes |
| Vibrator | Electric | Electric | Electric |
PLC-Based In-Truss Dust Collector
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Batcher Vent | No | No | Yes |
| Ducting | Quick Lock | Quick Lock | Quick Lock |
| Shroud | Yes | Yes | Yes |
| VH1083JP* | Yes | Yes | Yes |
*Auto Reclaim, Electric Vibrator, Level Indicators, Photohelic Gauge
Air
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Aeration Blower | Yes – Silo & Cement Batcher | Yes – Silo & Cement Batcher | Yes – Silo & Cement Batcher |
| Air Compressor | 15HP Piston | 15HP Piston | 20HP Piston |
| Air Valve Enclosure | No | Yes | Yes |
Water
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Holding Tank | No | No | Yes |
| Meter | 3″ Turbine | 3″ Turbine | 3″ Turbine |
| Y in Line* | No | No | Yes |
| 15 HP Pump | Future | Yes | Yes |
| Water Side | Left | Left | Left |
*Prior to Water Pump or Water Meter (Butterflies)
Other
| Feature | Essential | Performance | High-Performance |
|---|---|---|---|
| Axles | Triple | Triple | Triple |
| Controls Side | Right | Right | Right |
| Electrical | 460V / 3PH / 60HZ | 460V / 3PH / 60HZ | 460V / 3PH / 60HZ |
| 15 KVA Transformer | No | Yes | Yes |
| Smart Sensors | Optional | Optional | Optional |
| Tandem Landing Gear | Yes | Yes | Yes |
| Walkway | Yes | Yes | Yes |
Retractable Self Erect Mobile Plants
An optional upgrade, the hydraulic self erect package can be added to the mobile plant, auxiliary silo, conveyor, and horizontal shaft mixer. Our design allows cylinders to retract, protecting them from the caustic environment and costly maintenance.
Low Friction • Ultra Durable Batcher Liners
Increase Profit with Better Discharge Times & Liner Life
“These liners help unload so much quicker.”
David – Thomson Concrete
Only Available on All New Vince Hagan Plants
High Flo
Improved Discharge Times From Traditional Liner Materials
Durable
Less Wear Even With the Most Abrasive Materials
Quiet
Virtually Eliminates Vibrator Use to Reduce Community Noise Impact
Drop-In Replacement
Easily Replace Individual Liners When Needed
Rapid ROI
Improved Cycle Times Maximizes Daily Production
First to Industry Innovation from Vince Hagan
Vince Hagan has once again brought a new innovation to the industry with Turbo-Flo Armor™. This revolutionary polymer batcher liner promotes reliable and rapid aggregate flow due to industry lowest coefficient of friction. Freely moving materials virtually eliminates the need to use a vibrator, reducing your community noise impact.
The high wear material does not absorb moisture, does not degrade from UV exposure or freezing temperatures, and is designed to fit the batcher exactly reducing plugging and arching. All of these factors combine to make Turbo-Flo Armor™ a game-changing material bringing you rapid return on investment.
Reduce Noise Impact
Reduced friction improves material flow for minimal vibrator usage
“We started getting complaints about the noise. … With this product, the neighbors love us now because we don’t have to use the vibrator at all. You don’t have to turn the vibrator on, it just slides right off.”
High Flo
Increase production with improved discharge time
“Our materials jut seem to consolidate and are a little bit more sticky than in other parts of the country. … It unloads so much quicker. I can get a truck out almost two minutes faster.”
Ultra Durable
Withstands the most abrasive materials and exposure
“We were looking for a solution for abrasion resistance. … After thousands of yards, I don’t see any wear in the bolts, the actual product, or anything.”
Batch Plants in Action
Vince Hagan recently designed, manufactured, and installed an LPM Series Stationary Batch Plant, free standing dust collector, and conveyor in West Texas.
Vince Hagan recently designed, manufactured, and installed an LPM Series Stationary Batch Plant, free standing dust collector, and conveyor in West Texas.
Vince Hagan recently designed, manufactured, and installed an LP Series Stationary Batch Plant, free standing dust collector, and conveyor in Southern Texas.
Vince Hagan recently designed, manufactured, and installed an HSM Batch Plant, Overhead Silo, and conveyor in North Carolina.
Vince Hagan recently designed, manufactured, and installed an HT Performance Mobile Batch Plant and HCA Silo in Louisiana.
Vince Hagan recently designed, manufactured, and installed an HT Performance Mobile Batch Plant and HCA Silo in Louisiana.
Contact Your Regional Sales Manager
The Vince Hagan Company has been the nation’s leading innovator in concrete batching plants and equipment for over 60 years. Connect with your regional sales manager today to learn more about our equipment and get a customized quote for your project’s needs.
