Horizontal Shaft Mixer

HM-10 Series/RCC Mixer

The combination of mixer mobility and high production capabilities.

HM-10 Advantages

  • 400 YD³ Per Hour with a 30-second mix time

  • Hydraulic Self Erect Available

  • Long lasting cast ni-hard steel blades

  • 400 brinell hardness AR steel liners (replaceable)

  • Tungsten hardened shaft ends

  • Greatly reduces time chipping out

  • Special discharge chute for ready mix trucks, 40hp hydraulic system wet belt conveyor, and RCC upgrade available

  • Accepted by Army Corps of Engineers, All Military Branches, & Dept. of Transportation

  • 10, 8, & 4.5 YD³ drum sizes available

  • 21 Second discharge cycle

Overview

Vince Hagan combined mixer mobility and product consistency when we designed our patented Horizontal Shaft Spiral Blade Mixer. Fully trailerized and self erecting, it moves easily and inexpensively. Plus, you can often forego the need for concrete slabs. These mobility factors mean this mixer can be set up in a day, and on a fast-moving paving job. Additionally, the horizontal mixer does not require chipping out daily like it's tilt mixer counterpart. All of of these features improve your bottom line!

For decades, the largest pavers in the highest concrete production states have chosen the Vince Hagan Horizontal Shaft Mixer for production reliability and mobility.

Due to its quick cycle time, the Hagan Mixer produces up to 400 yards per hour with a 30-second mix time. A 20-second mix time has been approved for both 1”–3” slump pacing and 4”–6” slump general use concrete. This mixer is accepted by Army Corps of Engineers, All Military Branches, and Dept. of Transportation.

Adding the RCC upgrade makes this mixer the highest production and most portable RCC mixer on the market. It can mix high and low slump, slurry mixes, cement treated base and roller compacted concrete.

Trailer Features

  • Heavy duty portable trailer for ease of delivery and quick setup

  • Dual axle design to meet DOT requirements

  • Hydraulic Self Erect System Available - No Cranes Needed

  • All electrical and hydraulics mounted on trailer frame

  • Pre-piped and pre-wired for easy start-up

  • Highly portable for fewer loads of freight

Key Features

  • Designed to meet or exceed specs of PMMD & CPMB

  • 45 sec. mix time @ 1”-3” slump (Paving Use)

  • 30 sec. mix time @ 4”-6” slump (General Use)

  • Twin 125 HP Drives

  • Significant reduction in foundation requirements

  • Auto lube system

Automatic Grease System
Automatic Grease System
Twin 125 hp motors & oil bath
Twin 125 hp motors & oil bath
Self Erect Available
Self Erect Available

Optional RCC Mixer Upgrade

The Highest Production Portable RCC Mixer on the Market

  • Largest portable RCC mixer on the market
  • 8YD³ yield for RCC & CTB Mixes
  • Can mix high and low slump, slurry mixes, cement treated base, and roller compacted concrete
  • PMMD performance ranted for 30 second mix time in 4"-6" slump for general use and 4" slump of less paving mix
  • Provides exceptional operational flexibility in current heavy construction materials markets

  • Proven in the market on all types of jobs: hydroelectric dams, airport runways, mainline paving, commercial buildings, bridges, and all general construction concrete

  • Mixer chan charge all types of trucks including front-discharge mixers, boost-a-load mixers, conventional mixers, agitors, and any size dump trucks (portable concrete wetbelt for additional height and high speed discharge into any truck)
  • Standard mixes theoretical rating of 400 YD³ per hour - RCC & CTP mixes at 320 YD³ per hour (30 second mix time)

Specifications

Dimensions HM-10
Travel Dimensions:
Load Length
Load Height		 37’ 8 3/4”
14’
Operating Dimensions:
Length
Width
Height
Weight		 39’ 1”
10’ 5”
14’
70,500#
